Custom Fixtures for Testing and Production
We design and manufacture fixtures for SMT lines, functional testing and assembly operations. Each fixture is built around your PCB, test points, production process and operator workflow.
Fixture Types
- ICT and FCT test fixtures
- SMT pallets for wave soldering and reflow support
- Assembly jigs for positioning and locking
- Visual inspection and programming fixtures
| Item | Capability |
|---|---|
| Machining tolerance | ±0.02mm |
| Materials | Aluminum, steel, stainless steel, FR4, Bakelite, POM |
| Lead time | 3-7 days for prototype fixture |
